процессор сокет 370 Intel Pentium III 733/256/133 SL3XY

процессор сокет 370 Intel Pentium III 733/256/133 SL3XY

Нет в наличии
Рейтинг:

Нет в наличии 670
670 р.

  • Код товара: процессор сокет 370 Intel Pentium III 733/256/133 SL3XY
TypeCPU / Microprocessor
Market segmentDesktop
Family
Intel Pentium III
CPU part numbers
  • RB80526PZ733256 is an OEM/tray microprocessor
  • BX80526F733256 is a boxed microprocessor
  • BX80526F733256E is a boxed microprocessor
Frequency 733 MHz
Bus speed 133 MHz
Clock multiplier 5.5
Package370-pin Flip-Chip Pin Grid Array (FC-PGA)
1.95" x 1.95" (4.95 cm x 4.95 cm)
SocketSocket 370 / PGA370
Introduction date
Price at introduction
S-spec numbers
Part number


Part numberProduction processors

SL3XY
BX80526F733256
 +

BX80526F733256E


RB80526PZ733256
+
Architecture / Microarchitecture
MicroarchitectureP6
Processor core Coppermine
Core steppings cA2 (QM51, SL3T4, SL3VM)
cB0 (QP14, QS21, QS80, SL3XY, SL45Z)
cC0 (SL4CG, SL4M8)
cD0 (SL4ZL)
CPUIDs681 (SL3T4, SL3VM)
683 (QP14, QS21, SL3XY, SL45Z)
686 (SL4CG, SL4M8)
68A (SL4ZL)
Manufacturing process0.18 micron
28 million transistors
Die104.6mm2 (CPUID 0683h)
90mm2 (CPUID 0686h)
94.7mm2 (CPUID 068Ah)
Data width32 bit
Data bus width64 bit
The number of CPU cores1
The number of threads1
Floating Point UnitIntegrated
Level 1 cache size 16 KB 4-way set associative instruction cache
16 KB 4-way set associative data cache
Level 2 cache size Full-speed integrated 8-way set associative 256 KB
MultiprocessingUp to 2 processors
Extensions and Technologies
  • MMX instructions
  • SSE / Streaming SIMD Extensions
Low power features
  • AutoHALT state
  • Stop Grant state
  • Sleep state
  • Deep Sleep state
  • System Management Mode
Electrical / Thermal parameters
Min/Recommended/Max V core1.57V / 1.65V / 1.69V
1.62V / 1.7V / 1.74V
1.67V / 1.75V / 1.79V
Minimum/Maximum operating temperature 0°C - 80°C
Maximum power dissipation 24.82 Watt (1.7V core)
26.95 Watt (1.75V core)
Thermal Design Power 19.1 Watt
